4-Port USB 3.2 2 USB-C 2 USB-A w/ 15KV ESD Surge Protection
Part # CG-4P31CHUB-M
$131.95
Status: Low stock, please call or email for status
Volume Pricing
Qty: 1+
$131.95
Qty: 6+
$129.97
Qty: 12+
$128.98
Qty: 24+
$127.33
Qty: 48+
$126.34
Qty: 99+
$124.03
- Compliant with USB 3.2 Gen 2 Specifications
- Provides 1 USB3.2 Gen 2 Upstream Port with USB-C connector
- Each Port Supports 15KV (air) ESD Surge Protection
- Provides 4 USB3.2 Gen 2 Downstream Facing Ports (with 2 USB-C and 2 USB-A connectors)
- Full-Featured USB-C Port Enables Reversible Plug Orientation and Cable Direction
- Supports 10Gbps, 5Gbps, 480Mbps, 12Mbps and 1.5Mbps Speed
- Supports Multi Transaction Translators per Hub
- Supports Wide Range Input (+7~24V DC) Self-power Mode from the DC Jack or 2-pin Terminal Blocks
- Supports Port Status LED Indicators for each Port.
Product Documentation & Drivers
4-Port USB 3.2 2 USB-C 2 USB-A w/ 15KV ESD Surge Protection
Part # CG-4P31CHUB-M
Volume Pricing
Qty: 1+
$131.95
Qty: 6+
$129.97
Qty: 12+
$128.98
Qty: 24+
$127.33
Qty: 48+
$126.34
Qty: 99+
$124.03
Documentation
Description:
The CG-4P31CHUB-M is a USB3.2 Metal Hub that complies with the Universal Serial Bus (USB) Specifications Revision 3.1 Gen 2 and works up to 10Gbps. It provides 1 USB-C upstream port and 4 downstream facing ports with 2 USB-C and 2 USB-A connectors.
With the RISC-like USB controller, it supports simultaneous operation of any combination of SuperSpeed Plus(SS+), SuperSpeed(SS), High-Speed(HS), Full-Speed(FS), and Low-Speed(LS) devices. It is backward compatible with USB1.1, 2.0, USB3.2 Gen 1 legacy devices.
The CG-4P31CHUB-M provides a unique self-power mode to work with wide range (+7~24V DC) input DC power from its DC Jack or 2-pin terminal blocks. It supports fast USB charging specifications by turning its downstream ports from a Standard Downstream Port (SDP) into Charging Downstream Port (CDP) or Dedicated Charging Ports (DCP).
Since the USB is the most popular external port for the devices to connect to PCs, the CG-4P31CHUB-M provides an ideal solution to expand your USB ports immediately and save your USB investment.
Features:
- Compliant with USB3.2 Gen 2 Specification
- Metal Case with Different Mounting Options for Industrial Critical Applications
- Each Port Supports 15KV (air) ESD Surge Protection
- Upstream Facing Port: USB-C Connector
- Downstream Facing Ports: 2 x USB-C and 2 x USB-A
- Supports Type-C and Type-A Screw-Lock Cables
- Detects Flip-able/Reversible Plugging
- Supports 10Gbps (SS+), 5Gbps (SS)480Mbps (HS), 12Mbps (FS) and 1.5Mbps (LS) Speed
- Multi Transaction Translators (TT) per Hub
- Built-in Port Status Indicator LED for Each Port
- Supports Wide Range (+7~24V DC) Self-power Input
- Supports BC 1.2: SDP, CDP and DCP modes
- Charges all 4 USB Ports up to 2A Each Simultaneously
Sometimes you need a product in a flash and just want to verify an item is in stock. Other times you have a specific question regarding a product, shipping method, or your order. Use the form below and we will help. Please refrain from spam, we only log this information to our database for 24-hours and then it's gone.
Specifications
| Manufacturer: | Coolgear | Warranty: | 1 Year | Availability: | Limited Stock |
| Barcode: | 045079162853 | Ship Weight: | 1.51 | Condition: | New |
| Part Number: | CG-4P31CHUB-M | Color: | Black | Length/Size: | -- |
| USB Spec: | USB 3.2 Gen 2 | Max Data Rate: | 10 Gbps | Input Voltage: | 7 ~ 24V DC |
| Upstream Port: | Downstream Port(s): | 2x Type A USB 3.2 G2 2x Type C USB 3.2 G2 | Screw Lock Compatible: |
Yes |
Specifications
| Manufacturer: | Coolgear |
| Barcode: | 045079162853 |
| Part Number: | CG-4P31CHUB-M |
| Warranty: | 1 Year |
| Ship Weight: | 1.51 |
| Color: | Black |
| Availability: | Limited Stock |
| Condition: | New |
| USB Spec: | USB 3.2 Gen 2 |
| Max Data Rate: | 10 Gbps |
| Input Voltage: | 7 ~ 24V DC |
| Upstream Port: | |
| Downstream Port(s): | 2x Type A USB 3.2 G2 2x Type C USB 3.2 G2 |
| Screw Lock Compatible: |
Yes |
