Compact, Mountable USB 3.2 Gen 1 4 Port Hub
USB 3.2 Gen 1powered hub with industrial-grade chassis and surface mounting flanges. The CG-U3MINI4P-BPH is a 5V DC input, generation 1 USB 3.2 hub with ESD and Surge protection. This USB 3.2 Gen 1 Hub will support fast charging for Apple 1A/2.4A and Samsung Galaxy devices. Each port is protected individually to help keep your peripherals safe. The USB USB 3.2 Gen 1 Hub uses a GL 3510 chip, each port is on an individual circuit to maintain high current and protection. The GL3510 Hub controller chip features native fast-charging and complies with USB-IF battery charging specification rev1.2.

• Connect up to 4 USB devices and peripherals to your computer or laptop.
• Surface Mount or mount to a DIN rail in harsh industrial environments such as factories or warehouses.
• Add 4 fast-charging, data-communicating USB ports for ease-of-access for locations otherwise hard to access.

Specifications

• Compliant with USB 3.1 Gen 1 Specifications
• Upstream port supports Super-Speed (SS), High-Speed (HS) and Full-Speed (FS) traffic
• Downstream ports support SS, HS, FS, and Low-Speed (LS) traffic
• 1 control pipe and 1 interrupt pipe
• Backward compatible to USB specification Revision 2.0/1.1
• Compliant with USB Battery Charging Revision v1.2, supporting CDP, DCP, and ACA-Dock
• Downstream ports can be turned from a Standard Downstream Port (SDP) into Charging Downstream Port (CDP) or Dedicated Charging Port (DCP)
• Downstream devices can be charged while upstream VBUS is not present, which can be applied on wall charger applications
• Upstream port is capable of charging and data communicating simultaneously for portable devices supporting ACA-Dock or proprietary charging protocols
• Supporting Apple 1A/2.1A/2.4A and Samsung Galaxy devices fast-charging
• Compatible with Windows XP, 7, 8,10, and Mac OS X

• USB USB 3.2 Gen 1 4-Port Hub
• 3ft. USB A to B Cable for Hub

*Power Supply and Mounting screws not included. See SKU: CG-U3MINI4PH if power supply is required.
