USB-C 2.0 to Serial RS-232 Adapter w/ LED Indicators
Status: Available
USB C to Serial RS232 adapter uses the new type-C USB connector technology for easy, reversible connections. The same great tool of choice when supporting serial peripherals in newer computers without serial support with a C port host. Supported by Windows 11, this is an ideal solution for serial device support.
Compatibility
Product Documentation & Drivers
USB-C 2.0 to Serial RS-232 Adapter w/ LED Indicators
Compatibility
Documentation
USB C to RS232 Serial Adapter for Windows 11
This USB serial device is a USB C to RS-232 serial adapter compliant with USB 2.0 specifications, used to easily add a serial port to your computer even if they are unequipped with COM port ability.
The GM-FTDI2-LED-C supports peripherals requiring a serial RS-232 connection through a USB C type host port connection from your Laptop or Desktop computer. The USB C to serial adapter allows you to add a single serial port and monitor the status of your connections by using LED activity flashes.
When connection activity is present, the LED's will flash letting you know you have signal on the pins. The GM-FTDI2-LED-C offers an advanced an FTDI Chipset supported by Windows 11. The device is powered individually by the USB 2.0 Type-C port and is easy to install with Plug & Play, it easily tests RS-232 Host to Device link with backward compatibility with USB Spec 1.1.
Device Support:
- Supports reversible USB type-C connection only, can not be connected to any other USB port.
- PDA RS-232 Port support 56K Modem support Serial Mouse support+ Serial PC camera support.
- Fully compliant with USB Spec 2.0 Compliant USB Spec1.1.
- RS-232 - DB9 / M Data rate : Over 1000kbps.
- ESD Protection for RS-232 I/O' +-15KV RS-232 for DTE Mode
Additional Features & Specifications: LED Color:
- 1~4, 6~9 PIN Signal 0 : Green / Signal 1 : RED GND - RED - POWER PS. DB9-F PIN / 1,2,6,8,9 NO Input LED no light
- DCD , RXD, TXD, DTR , GND,DSR ,RTS ,CTS , RI
- Easy test RS-232 Host to Device link
- Supports USB C port connection
OS Support:
- Windows 7, 8, and Windows 10
- Linux, Mac OS 10.X
Package Contents:
- USB C to RS232 Serial Adapter with LED's
- Latest FTDI Driver (available for download)
- GM-FTDI2-LED Product Manual (available for download)
Sometimes you need a product in a flash and just want to verify an item is in stock. Other times you have a specific question regarding a product, shipping method, or your order. Use the form below and we will help. Please refrain from spam, we only log this information to our database for 24-hours and then it's gone.
Specifications
| Manufacturer: | Gearmo | Warranty: | 1 Year | Availability: | Available |
| Barcode: | 736983902542 | Ship Weight: | 0.19 | Condition: | New |
| Part Number: | GM-FTDI2-LED-C | Color: | Black | Length/Size: | 36 in |
| Port Count: | 1 | Port Type: | Male DB9 /W Nuts | Input Voltage: | Unspecified or N/A |
| Temperature(Op): | -40C ~ 85C | ESD Protection: | 15KV | Serial Modes: | RS232 |
| LEDs: | All Signals | Isolation: | -- | Chip: | -- |
Specifications
| Manufacturer: | Gearmo |
| Barcode: | 736983902542 |
| Part Number: | GM-FTDI2-LED-C |
| Warranty: | 1 Year |
| Ship Weight: | 0.19 |
| Color: | Black |
| Availability: | Available |
| Condition: | New |
| Port Count: | 1 |
| Port Type: | Male DB9 /W Nuts |
| Input Voltage: | Unspecified or N/A |
| Temperature(Op): | -40C ~ 85C |
| ESD Protection: | 15KV |
| Isolation: | -- |
| Serial Modes: | RS232 |
| LEDs: | All Signals |
| Chip: | -- |
