USB Ethernet Network Device Server over TCP/IP 10/100/1000 Mbps LAN
Status: Low stock, please call or email for status
Network-enabled USB Server for connecting USB devices over the 10/100/1000 Mbps Ethernet network running TCP/IP. Provides a simple and convenient way to extend a USB device over long distances
Compatibility


USB Ethernet Network Device Server over TCP/IP 10/100/1000 Mbps LAN

Compatibility


NetUSB-100iX4 USB Device Server 10/100/1000 Mbps
The NetUSB-100iX4 is a network-enabled USB Server for connecting USB devices over the 10/100/1000 Mbps Ethernet network running TCP/IP. By adding this USB to Ethernet Server to LAN, you can network-enable the USB device. It breaks the traditional five-meter USB cabling distance limitation. By this implementation, USB devices connected to NetUSB-100iX4 can be made available to remote clients over LAN- without a locally attached host PC.
The NetUSB-100iX4 provides a simple and convenient way to extend a USB device over long distances and allows for sharing that USB device with multiple users over Ethernet Network.
NetUSB-100iX4 Device Server Features:
- Supports wide input power range: DC9V~DC48V
- Extends USB cabling distance beyond five meters
- Compatible with USB 2.0 specification and backward compatible with USB 1.1
- Allows USB devices to be used and shared by client PCs over LAN
- Supports wide variety of USB devices
- Connects up to 4 devices using an additional USB Hub (not included)
- Provides Plug-n-Play and hot-swap functions same as on board USB port
- Access and monitor USB devices over a user-friendly application interface
- The NetUSB-100iX4 USB to Ethernet Server provides:
- RJ45 Ethernet to 1 USB 2.0 port
- Allows USB Devices to be used and shared by client PC's over LAN
- USB 2.0 High Speed Ports up to 480 Mbps speed
- Full 500 mA power provided to USB port
- Connects up to 4 devices using an additional USB Hub (not included)
- Supports wide variety of USB devices
- 10/100/1000 Mbps Ethernet support
- Supports IP addressing: Static and DHCP
- LEDs for system/ Ethernet status
- Field-upgradeable firmware
- Supports “Reset” button for system reset
- Supports “Default” button for configuration to default setting
- Input power range: DC9V~DC48V
- Compatible Windows XP/ 2003 Server/ Vista/ Windows 7/ Windows 8
- Regulatory approvals: FCC Class B (DoC) and CE
- RoHS compliant
Hardware Restore Factory Default Button located inside the housing:
The NetUSB-100iX4 USB server supports a Hardware Factory Default button to restore the default settings (like IP Address). You will need to open up the case. When the NetUSB-100iTX is powered on, press the factory default push button for 5 seconds. It will restore the default settings for the NetUSB-100iX4 USB Server.
Hardware Reset Button
The NetUSB-100iX4 USB server supports Hardware Reset Button to reset the hardware. When the Hardware Reset Button is pressed for a short duration, it will reset the NetUSB-100iX4 USB server system.
Sometimes you need a product in a flash and just want to verify an item is in stock. Other times you have a specific question regarding a product, shipping method, or your order. Use the form below and we will help. Please refrain from spam, we only log this information to our database for 24-hours and then it's gone.
Specifications
Manufacturer: | Coolgear | Warranty: | 1 Year | Availability: | Limited Stock |
Barcode: | 736983901699 | Ship Weight: | 0.87 | Condition: | New |
Part Number: | NetUSB-100iX4 | Color: | Gray | Length/Size: | -- |
Specifications
Manufacturer: | Coolgear |
Barcode: | 736983901699 |
Part Number: | NetUSB-100iX4 |
Warranty: | 1 Year |
Ship Weight: | 0.87 |
Color: | Gray |
Availability: | Limited Stock |
Condition: | New |
